6 bit 40MHz flash ADC
The ADC is able to convert the analog input signal into a 6 bit digital word for further processing.
Features:
- Full flash architecture
- Automatic offset correction
- Resolution: 6 bits
- Total harmonic distortion (THD): 1%(typ) / 2% (max)
- Effective number of bits: 5.5 bits (min)
- Differential non-linearity: 0.5 bits (max)
- Integral non-linearity: 1 bit (max)
- DC input voltage: 1.5 V (typ)
- Input bandwidth: 50 MHz (min)
- Delay clock to output: 1.5 ns (typ)
- Power supply: 3.3 V (typ)
- Temperature range: 0 to 70 oC
- 0.35 mm CMOS technology
